Anti-radiation shelter ARCA MAX 6.0 · 100 persons — view 1
Commercial Shelters

Anti-radiation shelter ARCA MAX 6.0 · 100 persons

Commercial shelter · 100 persons

On requestex. delivery & site prep

A larger-capacity certified shelter for business and public spaces. Anti-radiation shelter ARCA MAX 6.0 · 100 persons.

Sections
9
Vestibules
2 (closed)
Usable area
60.6 m²
Capacity
100 persons
Protection class
A-I
Ceiling thickness
700 mm

Overview

A larger-capacity certified shelter for business and public spaces. Anti-radiation shelter ARCA MAX 6.0 · 100 persons. ARCA is a multi-section reinforced-concrete bunker cast from high-grade C35/45 concrete with dense A500S reinforcement and a steel-fibre mix. Designed by leading engineers and proof-tested at the State Research Institute of Building Structures, it is certified to the highest protection classes (A-II to A-IV), absorbs air-blast overpressure above 300 kPa and reduces radiation exposure by up to a factor of 5000. Every unit ships fully equipped — reinforced airtight doors, forced ventilation, heating, power, seating and first-aid and fire-safety kits — with a 50-year warranty on the concrete structure. Every PerusTurva product is built to the CPS — Civil Protection Standard — a new-generation benchmark validated by engineering expertise and live-fire testing against modern threats, including a 120 mm mine, a 125 mm tank round and a Shahed-136 strike-drone warhead.

Specifications

Sections
9
Vestibules
2 (closed)
Usable area
60.6 m²
Capacity
100 persons
Protection class
A-I
Ceiling thickness
700 mm
Wall & floor thickness
350 mm
Reinforced concrete
class S35/45
