ARCA NOVA 3.2
Anti-radiation multi-section bunker · 27 persons
A larger-capacity certified shelter for business and public spaces. ARCA NOVA 3.2.
Overview
A larger-capacity certified shelter for business and public spaces. ARCA NOVA 3.2. ARCA is a multi-section reinforced-concrete bunker cast from high-grade C35/45 concrete with dense A500S reinforcement and a steel-fibre mix. Designed by leading engineers and proof-tested at the State Research Institute of Building Structures, it is certified to the highest protection classes (A-II to A-IV), absorbs air-blast overpressure above 300 kPa and reduces radiation exposure by up to a factor of 5000. Every unit ships fully equipped — reinforced airtight doors, forced ventilation, heating, power, seating and first-aid and fire-safety kits — with a 50-year warranty on the concrete structure. Every PerusTurva product is built to the CPS — Civil Protection Standard — a new-generation benchmark validated by engineering expertise and live-fire testing against modern threats, including a 120 mm mine, a 125 mm tank round and a Shahed-136 strike-drone warhead.
Included in the base configuration
- Reinforced airtight doors (440 kPa)
- Forced ventilation system
- Thermal fan heating
- Full electrical network
- Seating benches
- Fire extinguisher & first-aid kit
- Certificate of conformity
- Optional: A/C, WC, Wi-Fi, smart lock, CCTV
Specifications
- Usable area
- 16.25 m²
- Capacity
- 27 persons
- Weight
- 117 t
- Protection class
- A-II A-III, A-IV
- Rebar content
- 40%
- Wall & ceiling thickness
- 350 mm
- Sections
- 6
- Overall size (with vestibules)
- 3.20 x 11.00 x 3.20 m
- Reinforced concrete
- class S35/45.
- Embedded steel
- steel grade S245.
- Rebar
- class A500S (rozrakhovana na trishchynostiikist).
- Type
- above-ground, underground, partially embedded, block-modular.
